Geomembrane is a waterproof and barrier material made primarily from high molecular polymer, which mainly works by using the impermeability of the plastic film to seal off leakage paths in dams, with its high tensile strength and elongation to withstand water pressure and accommodate dam deformation.
Geomembrane Description
Geomembrane is a waterproof and barrier material made primarily from high molecular polymer, which mainly works by using the impermeability of the plastic film to seal off leakage paths in dams, with its high tensile strength and elongation to withstand water pressure and accommodate dam deformation.
| Technical Indicators of Geomembranes for Landfills | ||||||||
| Serial number | Project | Indicator | ||||||
| 1 | Thickness（mm） | 0.75 | 1 | 1.25 | 1.5 | 2 | 2.5 | 3 |
| 2 | Density | ≥0.910 | ||||||
| 3 | Tensile Yield Strength (Machine Direction, Cross Direction)N/mm | ≥11 | ≥15 | ≥18 | ≥22 | ≥29 | ≥37 | ≥44 |
| 1 | Tensile Breaking Strength (Machine Direction, Cross Direction)N/m | ≥20 | ≥27 | ≥33 | ≥40 | ≥53 | ≥67 | ≥80 |
| 5 | Yield Elongation (Machine Direction, Cross Direction)% | ≥12 | ||||||
| 6 | Breaking Elongation (Machine Direction, Cross Direction)% | ≥700 | ||||||
| 7 | Right-Angle Tear Load (Machine Direction, Cross Direction)N | >93 | ≥125 | ≥1060 | ≥190 | ≥250 | ≥315 | ≥375 |
| 8 | Puncture Resistance Strength N | ≥240 | ≥320 | ≥400 | ≥480 | ≥640 | ≥800 | ≥960 |
| 9 | Carbon Black Content % | 2.0-3.0 | ||||||
Product Classification
LDPE geosynthetic membrane, LLDPE geosynthetic membrane, HDPE geosynthetic membrane, ECB geosynthetic membrane, PVC geosynthetic membrane, etc.
Main Applications
1. Waterproofing for landfill sites, sewage or waste treatment plants.
2. River embankments, lake dams, tailings dams, sewage dams, and reservoir areas, canals, liquid storage pits (pits, mines).
3. Waterproofing and lining for subways, basements, tunnels, and tunnel passages.
4. Used for waterproofing of subgrades and other foundation soil salinization.
5. Horizontal waterproofing covers in front of embankments and dams, vertical waterproofing layers of foundations, construction cofferdams, and bottom material sites.
6. Waterproofing layers for highways, expressways, and railways, subgrades, expansive soils, and collapsible loess.
7. In residential construction, mainly used for roof waterproofing.
